| ITEM | UNIT | MODULE SPECIFICATION | REMARK | |
|---|---|---|---|---|
| Nominal Capacity | Ah | 600Ah | Discharge at 0.5C | |
| Actual Capacity | Ah | 600Ah | less then 300A | |
| Configuration | – | 6pcs 16S1P modulars+ 1pc 1.4M 19″ server rack cabinet+combiner wires | ||
| Operating Temp. | Min. | ℃ | 0 (Charge).-20 (Discharge) | @ Temp Sensor |
| Max. | ℃ | 55 | ||
| Storage Temp. | Min. | ℃ | -20 | |
| Max. | ℃ | 55 | ||
| Nominal Voltage | V | 51.2 | Cell 3.2V | |
| Max. Voltage | V | 58.4 | Cell 3.65V | |
| Min. Voltage | V | 40 | Cell 2.5V | |
| Nominal Energy Content | kWh | ≥ 30kWh /15kw max | ||
| Weight | Kg | ≤400kg | ||
| Resistance Consistency (10s, 25℃, 30%SOC, BOL) | – | -15%/+10% DC-IR | ||
| Discharge Operation max current (10s, 25℃, SOC50%, BOL) | A | 600 | 120 Per 1 module | |
| Charge Operation max current (10s, 25℃, SOC 50% BOL) | A | 300A | 90Per 1 module | |
| Continuous Discharge Operation current (25℃, SOC50%, BOL) | A | 300A | 105 Per 1 module | |
| Continuous Charge Operation current (25℃, SOC 50% BOL) | A | 300Amps | 52.5 Per 1 module | |
| Standard Charge (@ 25℃ ) | – | Constant Current: ≤0.5C Constant Voltage:3.65V End Condition(Cut off):
≥0.02C |
for cells | |
| The state of charge(SOC) of the module | – | SOC 30%±3% | before shipping | |
| Self Discharge Rate(SOC 100%, 25℃ , Loss/Month， @BOL) | % | Max 3 | ||
| Safety and Reliability | – | Compliance with QC/T 743 test standard | GBT Certificate @cell | |
| Insulation | MΩ | Min 20MΩ/1000VDC, 25℃±5℃, RH50% | ||
| Cooling type | – | Natural(Passive) Convection | (Air Cooling) | |
DW-30kw Lithium Battery Features
Dawnice 30kWh Home Battery, a state-of-the-art Lithium Iron Phosphate Battery that sets new benchmarks in safety and durability within the lithium chemistry domain. Boasting an impressive capacity for over 6000 cycles, the DW-30kWh battery bank can be recharged multiple times, all while delivering a 100% depth of discharge.
The Dawnice 30kWh Lithium Ion Battery proves to be an ideal solution across various applications, including solar power, Telecom field, Wind power, and deep cycle requirements. Its versatile design and robust performance make it a reliable choice for diverse energy needs.
Featuring a Built-In Battery Management System (BMS), this cutting-edge battery is equipped with comprehensive management of Voltage, Current, Temperature, and Health parameters. This advanced system ensures the utmost protection and efficiency during operation.
Elevate your energy storage with the Dawnice 30kWh Home Battery, and experience a seamless blend of innovation, safety, and endurance for all your power demands.
Computer Monitor software with BMS
The built-in battery management system (BMS) can be connected to computer software for monitoring the battery’s status and other pack information. Additionally, users can define customized functions, and easily adjust BMS communication protocols for different inverters. Professional users have the ability to set various protection values, such as overcharge, over-discharge, and temperature thresholds. However, these advanced settings should only be adjusted by professional users with the necessary knowledge and expertise.
Certifications:
Lithium batteries are among the most commonly used energy storage units in today’s electronic devices. While they present distinct performance advantages in comparison to other battery chemistries, lithium batteries also present distinct safety concerns that must be addressed to ensure safety for end-product users.
All Coremax Solar energy storage batteries has already pass certifications like MSDS, UN38.3, IEC, CE. In additional, We can also provide other related test report accroding to the purchase order.
Lithium batteries are “dangous goods” GD goods. No matter shipping by air or sea freight. It require the test report and certifications. Please feel free to contact us.
